CD 1000-S/SP6
TRANSDUCERManufacturer: LEM USA Inc.
Categories: Current Sensors
Quality Control: Learn More
Current Sensor 1200A 1 Channel Closed Loop Bidirectional Module, Single Pass Through
Additional Information
Series: CDRoHS Status: RoHS CompliantManufacturer Lead Time: 14 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Module, Single Pass Through |
| Polarization | Bidirectional |
| Sensitivity | - |
| Mounting Type | Chassis Mount |
| Output | Current |
| Frequency | DC ~ 10kHz |
| Accuracy | ±3% |
| Operating Temperature | -25°C ~ 70°C |
| Voltage - Supply | 15V ~ 24V |
| Response Time | 40µs |
| Sensor Type | Closed Loop |
| Linearity | ±1% |
| For Measuring | AC/DC |
| Current - Supply (Max) | 40mA |
| Current - Sensing | 1200A |
| Supplier Device Package | - |
| Grade | - |
| Number of Channels | 1 |
| Qualification | - |
