FCX10852_RES-D
LENS CLR 13DEG DIFFUSER ADH TAPEManufacturer: Ledil
Categories: Lenses
Quality Control: Learn More
Ledil FCX10852-RES-D is a clear, diffused polycarbonate lens with a 13° viewing angle, designed for single LED applications. This Rose series component features an integrated holder and is supplied with adhesive tape for convenient mounting. The square lens with a flat top measures 21.6mm x 21.6mm. It is optimized for uniform light distribution, making it suitable for general illumination, architectural lighting, and automotive applications requiring controlled diffusion. The material's durability ensures reliable performance in demanding environments.
Additional Information
Series: RoseRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Color | Clear |
| Mounting Type | Adhesive Tape |
| Material | Polycarbonate |
| Type | Lens With Holder |
| Viewing Angle | 13° |
| Optical Pattern | Diffuser |
| Lens Transparency | Diffused |
| Lens Style | Square with Flat Top |
| Lens Size | 21.6mm x 21.6mm |
| For Use With/Related Manufacturer | Lumileds |
| Number of LEDs | 1 |
