LC4128ZC-42M132C
IC CPLD 128MC 4.2NS 132CSBGAManufacturer: Lattice Semiconductor Corporation
Categories: CPLDs (Complex Programmable Logic Devices)
Quality Control: Learn More
Lattice Semiconductor Corporation ispMACH® 4000Z series LC4128ZC-42M132C is a high-performance CMOS Complex Programmable Logic Device (CPLD). This device features 128 macrocells and 8 logic array blocks, providing a flexible platform for logic implementation. With a typical propagation delay of 4.2 ns, it is suitable for high-speed applications. The LC4128ZC-42M132C offers 96 user I/O pins and operates with an internal supply voltage of 1.7V to 1.9V. It is available in a 132-CSBGA (8x8) package, designed for surface mounting. This CPLD is In System Programmable and finds application in industrial, communication, and consumer electronics sectors. Operating temperature range is 0°C to 90°C (TJ).
Additional Information
Series: ispMACH® 4000ZRoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 132-LFBGA, CSPBGA |
| Mounting Type | Surface Mount |
| Programmable Type | In System Programmable |
| Number of Macrocells | 128 |
| Operating Temperature | 0°C ~ 90°C (TJ) |
| Delay Time tpd(1) Max | 4.2 ns |
| Supplier Device Package | 132-CSBGA (8x8) |
| Number of Logic Elements/Blocks | 8 |
| Voltage Supply - Internal | 1.7V ~ 1.9V |
| Number of I/O | 96 |
| Programmable | Not Verified |
