ISPLSI 2096E-100LQ128
IC CPLD 96MC 10NS 128QFPManufacturer: Lattice Semiconductor Corporation
Categories: CPLDs (Complex Programmable Logic Devices)
Quality Control: Learn More
Lattice Semiconductor Corporation's ispLSI® 2000E series device, part number ISPLSI-2096E-100LQ128, is a Complex Programmable Logic Device (CPLD) featuring 96 macrocells and 24 logic array blocks. This 128-QFP packaged component offers a maximum input-to-output propagation delay of 10 ns, supporting in-system programmability. With 96 I/O pins and an approximate 4000 gate count, it is well-suited for various applications in telecommunications, data communications, and industrial control systems. The device operates with an internal supply voltage range of 4.75V to 5.25V and is designed for surface mounting. Packaging is provided in trays.
Additional Information
Series: ispLSI® 2000ERoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 128-BQFP |
| Mounting Type | Surface Mount |
| Programmable Type | In System Programmable |
| Number of Gates | 4000 |
| Number of Macrocells | 96 |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Delay Time tpd(1) Max | 10 ns |
| Supplier Device Package | 128-PQFP (28x28) |
| Number of Logic Elements/Blocks | 24 |
| Voltage Supply - Internal | 4.75V ~ 5.25V |
| Number of I/O | 96 |
| Programmable | Not Verified |
