DMC-20261NYJ-LY-CKE-CNN
LCD MOD 40DIG 20X2 TRANS YLW/GRNManufacturer: Kyocera International, Inc.
Categories: LCD, OLED Character and Numeric
Quality Control: Learn More
Kyocera International, Inc. presents the DMC-20261NYJ-LY-CKE-CNN, a character display module featuring a 20x2 character format with a 5 x 8 dot matrix per character. This STN - Super-Twisted Nematic display offers transmissive mode operation and is illuminated by a Yellow/Green LED backlight. The module provides yellow text on a green background, with a character size of 5.55mm H x 3.20mm W and a dot size of 0.60mm W x 0.65mm H. It utilizes a parallel interface for data transfer. The operating temperature range is -20°C to 70°C, and the supply voltage is 4.5V to 5.5V. The overall dimensions are 116.00mm x 37.00mm x 15.70mm, with a viewing area of 83.00mm L x 18.60mm W. This component is suitable for industrial automation, test and measurement equipment, and medical instrumentation applications.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Display Type | STN - Super-Twisted Nematic |
| Display Mode | Transmissive |
| Backlight | LED - Yellow/Green |
| Interface | Parallel |
| Operating Temperature | -20°C ~ 70°C |
| Voltage - Supply | 4.5V ~ 5.5V |
| Viewing Area | 83.00mm L x 18.60mm W |
| Character Size | 5.55mm H x 3.20mm W |
| Display Format | 20 x 2 |
| Character Format | 5 x 8 Dots |
| Dot Size | 0.60mm W x 0.65mm H |
| Outline L x W x H | 116.00mm x 37.00mm x 15.70mm |
| Text Color | Yellow |
| Background Color | Green |
| Number of Characters | 40.0 |
