SM527C156KBL480
CAP CER 15UF 500V X7R 6SMDGWManufacturer: KYOCERA AVX
Categories: Ceramic Capacitors
Quality Control: Learn More
KYOCERA AVX SM Series SM527C156KBL480 is a 15 µF ±10% 500V ceramic capacitor with an X7R temperature coefficient. This stacked SMD component features low Equivalent Series Inductance (ESL) and is designed for high-voltage applications. The capacitor is housed in a 6 L-Lead package, with dimensions of 0.300" L x 0.250" W (7.62mm x 6.35mm) and a maximum thickness of 0.650" (16.50mm). Operating across a temperature range of -55°C to 125°C, it is suitable for surface mount applications. Typical uses include SMPS filtering, bypass, and decoupling circuits.
Additional Information
Series: SMRoHS Status: RoHS non-compliantManufacturer Lead Time: 30 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±10% |
| Lead Style | L-Lead |
| Features | Low ESL (Stacked), High Voltage |
| Packaging | Bulk |
| Voltage - Rated | 500V |
| Package / Case | Stacked SMD, 6 L-Lead |
| Temperature Coefficient | X7R |
| Size / Dimension | 0.300"" L x 0.250"" W (7.62mm x 6.35mm) |
| Mounting Type | Surface Mount, MLCC |
| Operating Temperature | -55°C ~ 125°C |
| Applications | SMPS Filtering, Bypass, Decoupling |
| Lead Spacing | - |
| Ratings | - |
| Height - Seated (Max) | - |
| Thickness (Max) | 0.650"" (16.50mm) |
| Capacitance | 15 µF |
