WP7113SRC/DU
LED RED CLEAR T-1 3/4 T/HManufacturer: Kingbright
Categories: LED Indication - Discrete
Quality Control: Learn More
Kingbright WP7113SRC-DU is a discrete red LED with a forward voltage of 1.85V (typical) and a dominant wavelength of 640nm. This through-hole mounted component features a clear, domed T-1 3/4 lens with a 5mm diameter. Delivering a luminous intensity of 500mcd at a test current of 20mA, it has a narrow viewing angle of 20 degrees. The component is supplied in bulk packaging. This Kingbright LED is suitable for various indication applications across industries such as consumer electronics, industrial automation, and telecommunications.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | Radial |
| Color | Red |
| Size / Dimension | 5.00mm Dia |
| Mounting Type | Through Hole |
| Millicandela Rating | 500mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 1.85V |
| Lens Color | Colorless |
| Current - Test | 20mA |
| Viewing Angle | 20° |
| Height (Max) | 8.60mm |
| Wavelength - Peak | 655nm |
| Wavelength - Dominant | 640nm |
| Supplier Device Package | T-1 3/4 |
| Lens Transparency | Clear |
| Lens Style | Round with Domed Top |
| Lens Size | 5mm, T-1 3/4 |
Request a Quote
