WP1503SRD
LED RED DIFFUSED T-1 3/4 T/HManufacturer: Kingbright
Categories: LED Indication - Discrete
Quality Control: Learn More
Kingbright WP1503SRD is a red diffused LED, T-1 3/4 package, radial mounting. This discrete indicator features a typical forward voltage of 1.85V at 20mA test current, with a dominant wavelength of 640nm and peak wavelength of 655nm. The diffused lens provides a wide 60° viewing angle, achieving 260mcd luminous intensity. Commonly utilized in industrial control systems, consumer electronics, and automotive applications, this component is supplied in bulk packaging. The lens is red with a round, domed top measuring 5mm in diameter.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | Radial |
| Color | Red |
| Size / Dimension | 5.00mm Dia |
| Mounting Type | Through Hole |
| Millicandela Rating | 260mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 1.85V |
| Lens Color | Red |
| Current - Test | 20mA |
| Viewing Angle | 60° |
| Height (Max) | 8.60mm |
| Wavelength - Peak | 655nm |
| Wavelength - Dominant | 640nm |
| Supplier Device Package | T-1 3/4 |
| Lens Transparency | Diffused |
| Lens Style | Round with Domed Top |
| Lens Size | 5mm, T-1 3/4 |
