APG0603VGC-TT-5MAV
LED GREEN CLEAR 2SMDManufacturer: Kingbright
Categories: LED Indication - Discrete
Quality Control: Learn More
Kingbright HELI-UM series LED, part number APG0603VGC-TT-5MAV. This green LED features a 527nm dominant wavelength and 518nm peak wavelength. It is designed for surface mounting in a 2-SMD, 0201 package, measuring 0.65mm x 0.35mm. The component offers a typical forward voltage of 3V and a test current of 5mA, yielding a millicandela rating of 80mcd. The clear, colorless lens has a rectangle with a flat top style and a 145° viewing angle. Packaged on tape and reel (TR), this discrete LED is suitable for applications in industrial automation and consumer electronics.
Additional Information
Series: HELI-UMRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 2-SMD, 0201 |
| Color | Green |
| Size / Dimension | 0.65mm L x 0.35mm W |
| Mounting Type | Surface Mount |
| Millicandela Rating | 80mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 3V |
| Lens Color | Colorless |
| Current - Test | 5mA |
| Viewing Angle | 145° |
| Height (Max) | 0.25mm |
| Wavelength - Peak | 518nm |
| Wavelength - Dominant | 527nm |
| Supplier Device Package | 2-SMD |
| Lens Transparency | Clear |
| Lens Style | Rectangle with Flat Top |
| Lens Size | 0.35mm x 0.65mm |
Request a Quote
Clients Also Buy
APG0603PBC-TT-5MAV
