AM2520SRC03
LED RED CLEAR SMDManufacturer: Kingbright
Categories: LED Indication - Discrete
Quality Control: Learn More
Kingbright AM2520SRC03 is a red, 640nm LED designed for discrete indication applications. This surface-mount component features a 2-SMD, Gull Wing package with a colorless, clear lens and a domed top measuring 1.90mm in diameter. With a typical forward voltage of 1.85V and a peak wavelength of 660nm, it achieves a millicandela rating of 600mcd at a 20mA test current. The component’s dimensions are 2.50mm L x 2.00mm W, with a maximum height of 2.90mm and a viewing angle of 20°. This LED is supplied on tape and reel. It finds application in various industries including consumer electronics, industrial automation, and medical devices.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 2-SMD, Gull Wing |
| Color | Red |
| Size / Dimension | 2.50mm L x 2.00mm W |
| Mounting Type | Surface Mount |
| Millicandela Rating | 600mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 1.85V |
| Lens Color | Colorless |
| Current - Test | 20mA |
| Viewing Angle | 20° |
| Height (Max) | 2.90mm |
| Wavelength - Peak | 660nm |
| Wavelength - Dominant | 640nm |
| Supplier Device Package | SMD |
| Lens Transparency | Clear |
| Lens Style | Round with Domed Top |
| Lens Size | 1.90mm Dia |
