DC10SRWA
LED CBI 10-SEG RED THROUGH HOLEManufacturer: Kingbright
Categories: Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Quality Control: Learn More
Kingbright DC10SRWA is a ten-segment LED bar graph indicator designed for through-hole mounting. This component features ten individual red LEDs, each with a diffused white lens, providing a clear visual display. Operating at a forward voltage of 1.85V and a current of 30mA, the DC10SRWA offers a typical luminous intensity of 30mcd per element. The component's DIP package and bar graph configuration make it suitable for applications in industrial control, instrumentation, and automotive displays where status indication or analog level representation is required. The peak wavelength for the red LEDs is 660nm.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Current | 30mA |
| Color | Red (x 10) |
| Voltage Rating | 1.85V |
| Mounting Type | Through Hole |
| Millicandela Rating | 30mcd |
| Configuration | Bar - 10 Wide, DIP |
| Viewing Angle | - |
| Lens Type | Diffused, White |
| Wavelength - Peak | 660nm |
| Lens Style | - |
| Lens Size | - |
