CKC33C144KEGLC7805

CAP CER 0.14UF 1.2KV C0G 3640

Manufacturer: KEMET

Categories: Ceramic Capacitors

Quality Control: Learn More

KEMET KC Link Comm C0G series CKC33C144KEGLC7805 is a 0.14 µF ceramic capacitor with a ±10% tolerance and a 1200V (1.2kV) voltage rating. This MLCC features a C0G/NP0 temperature coefficient, ensuring stable performance across its -55°C to 150°C operating temperature range. The capacitor's 3640 (9110 Metric) package, measuring 9.30mm x 10.20mm with a maximum thickness of 8.30mm, is designed for surface mounting. Key characteristics include low ESL, high voltage capability, and suitability for high-temperature applications. This component is supplied on tape and reel. It finds application in general-purpose uses.

Additional Information

Series: KC Link Comm C0GRoHS Status: ROHS3 CompliantManufacturer Lead Time: 23 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:
Technical Details:
Tolerance±10%
Lead Style-
FeaturesLow ESL, High Voltage, High Temperature
PackagingTape & Reel (TR)
Voltage - Rated1200V (1.2kV)
Package / Case3640 (9110 Metric)
Temperature CoefficientC0G, NP0
Size / Dimension0.366"" L x 0.402"" W (9.30mm x 10.20mm)
Mounting TypeSurface Mount, MLCC
Operating Temperature-55°C ~ 150°C
ApplicationsGeneral Purpose
Lead Spacing-
Ratings-
Height - Seated (Max)-
Thickness (Max)0.327"" (8.30mm)
Failure Rate-
Capacitance0.14 µF
