DX07WH24JA3R1200
WATERPROOF IPX7 USB-C RIGHT ANGLManufacturer: JAE Electronics
Categories: USB, DVI, HDMI Connector Assemblies
Quality Control: Learn More
USB-C (USB TYPE-C) USB 3.2 Gen 2 (USB 3.1 Gen 2, Superspeed + (USB 3.1)) Receptacle Connector 24 Position Surface Mount, Right Angle; Through Hole
Additional Information
Series: DX07RoHS Status: ROHS3 CompliantManufacturer Lead Time: 15 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Voltage - Rated | 20VAC |
| Number of Contacts | 24 |
| Connector Type | USB-C (USB TYPE-C) |
| Gender | Receptacle |
| Current Rating (Amps) | 0.25A, 1.25A, 5A, 6.25A |
| Mounting Type | Surface Mount, Right Angle; Through Hole |
| Shielding | Shielded |
| Operating Temperature | -30°C ~ 80°C |
| Specifications | USB 3.2 Gen 2 (USB 3.1 Gen 2, Superspeed + (USB 3.1)) |
| Termination | Solder |
| Ingress Protection | IPX7 - Waterproof |
| Mounting Feature | Horizontal |
| Mating Cycles | 10000 |
| Number of Ports | 1 |
