IXYX25N250CV1
IGBT 2500V 235A PLUS247Manufacturer: IXYS
Categories: Single IGBTs
Quality Control: Learn More
IGBT 2500 V 95 A 937 W Through Hole PLUS247™-3
Additional Information
Series: XPT™RoHS Status: ROHS3 CompliantManufacturer Lead Time: 44 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-247-3 Variant |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Input Type | Standard |
| Reverse Recovery Time (trr) | 220 ns |
| Vce(on) (Max) @ Vge, Ic | 4V @ 15V, 25A |
| Supplier Device Package | PLUS247™-3 |
| IGBT Type | - |
| Td (on/off) @ 25°C | 15ns/230ns |
| Switching Energy | 8.3mJ (on), 7.3mJ (off) |
| Test Condition | 1250V, 25A, 5Ohm, 15V |
| Gate Charge | 147 nC |
| Current - Collector (Ic) (Max) | 95 A |
| Voltage - Collector Emitter Breakdown (Max) | 2500 V |
| Current - Collector Pulsed (Icm) | 235 A |
| Power - Max | 937 W |
Request a Quote
