DSEI12-12A
DIODE GEN PURP 1.2KV 11A TO220ACManufacturer: IXYS
Categories: Single Diodes
Quality Control: Learn More
IXYS DSEI12-12A is a general-purpose diode designed for high voltage applications. This component features a 1200 V reverse voltage (Vr) and an average rectified current (Io) of 11 A. The forward voltage drop (Vf) is a maximum of 2.6 V at 12 A. With a reverse leakage current of 250 µA at 1200 V, it offers efficient operation. The TO-220AC package, suitable for through-hole mounting, houses a standard technology diode. Its operating junction temperature range is -40°C to 150°C. The DSEI12-12A is classified as a fast recovery diode with a reverse recovery time (trr) of 70 ns, making it suitable for power switching and rectification in industrial and automotive sectors.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-2 |
| Mounting Type | Through Hole |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 70 ns |
| Technology | Standard |
| Capacitance @ Vr, F | - |
| Current - Average Rectified (Io) | 11A |
| Supplier Device Package | TO-220AC |
| Operating Temperature - Junction | -40°C ~ 150°C |
| Voltage - DC Reverse (Vr) (Max) | 1200 V |
| Voltage - Forward (Vf) (Max) @ If | 2.6 V @ 12 A |
| Current - Reverse Leakage @ Vr | 250 µA @ 1200 V |
