DSA75-16B
DIODE AVAL 1.6KV 110A DO203ABManufacturer: IXYS
Categories: Single Diodes
Quality Control: Learn More
The IXYS DSA75-16B is a high-performance avalanche diode designed for demanding power electronic applications. Featuring a robust DO-203AB (DO-5) stud mount package, this component offers a substantial 1600V reverse voltage rating and an average rectified current capability of 110A. The DSA75-16B incorporates avalanche technology, providing enhanced protection against voltage transients. Its forward voltage drop is rated at a maximum of 1.17V at 150A, with a reverse leakage of 6mA at 1600V. Operating within a junction temperature range of -40°C to 180°C, this diode exhibits standard recovery characteristics exceeding 500ns. This component is frequently utilized in power conversion, industrial motor control, and high-voltage power supply systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | DO-203AB, DO-5, Stud |
| Mounting Type | Chassis, Stud Mount |
| Speed | Standard Recovery >500ns, > 200mA (Io) |
| Technology | Avalanche |
| Capacitance @ Vr, F | - |
| Current - Average Rectified (Io) | 110A |
| Supplier Device Package | DO-203AB |
| Operating Temperature - Junction | -40°C ~ 180°C |
| Voltage - DC Reverse (Vr) (Max) | 1600 V |
| Voltage - Forward (Vf) (Max) @ If | 1.17 V @ 150 A |
| Current - Reverse Leakage @ Vr | 6 mA @ 1600 V |
