DS1-12D
DIODE GEN PURP 1.2KV 2.3A RADIALManufacturer: IXYS
Categories: Single Diodes
Quality Control: Learn More
The IXYS DS1-12D is a general-purpose diode featuring a 1200V reverse voltage capability and a 2.3A average rectified forward current. This through-hole mounted component utilizes standard recovery technology, with a typical forward voltage drop of 1.3V at 7A. It exhibits a reverse leakage current of 700µA at its maximum reverse voltage of 1200V. The device operates across a junction temperature range of -40°C to 150°C and comes packaged in a radial configuration within a box. This diode is suitable for applications in power supply rectification, motor control, and general industrial power conversion.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BoxDownload Free CAD Model:
Technical Details:
| Packaging | Box |
| Package / Case | Radial |
| Mounting Type | Through Hole |
| Speed | Standard Recovery >500ns, > 200mA (Io) |
| Technology | Standard |
| Capacitance @ Vr, F | - |
| Current - Average Rectified (Io) | 2.3A |
| Supplier Device Package | - |
| Operating Temperature - Junction | -40°C ~ 150°C |
| Voltage - DC Reverse (Vr) (Max) | 1200 V |
| Voltage - Forward (Vf) (Max) @ If | 1.3 V @ 7 A |
| Current - Reverse Leakage @ Vr | 700 µA @ 1200 V |
