SJ4008DS2TP
8 AMP HIGH TEMPERATURE SENSITIVEManufacturer: IXYS
Categories: SCRs
Quality Control: Learn More
SCR 400 V 8 A Sensitive Gate Surface Mount TO-252AA
Additional Information
Series: SJxx08xSxRoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: ActivePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Mounting Type | Surface Mount |
| SCR Type | Sensitive Gate |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Current - Hold (Ih) (Max) | 6 mA |
| Current - Gate Trigger (Igt) (Max) | 200 µA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 83A, 100A |
| Current - On State (It (AV)) (Max) | 5.1 A |
| Voltage - Gate Trigger (Vgt) (Max) | 800 mV |
| Voltage - On State (Vtm) (Max) | 1.6 V |
| Current - Off State (Max) | 5 µA |
| Supplier Device Package | TO-252AA |
| Current - On State (It (RMS)) (Max) | 8 A |
| Voltage - Off State | 400 V |
Request a Quote
