IXYS N1140LN140 is a standard recovery SCR designed for high-power applications with a repetitive peak off-state voltage of 1.4 kV. This component features a high RMS on-state current rating of 2565 A and an average on-state current of 1315 A. The N1140LN140 has a non-repetitive surge current capability of 19500 A at 50 Hz. It requires a gate trigger current of 250 mA and a gate trigger voltage of 2.5 V. The holding current (Ih) is a maximum of 300 mA, and the off-state current is 100 mA. With an on-state voltage drop (Vtm) of 1.87 V, this SCR is suitable for industrial power control, motor drives, and power supply applications. The device is chassis mountable and operates within a temperature range of -60°C to 130°C. The package is TO-200AB, B-PuK, supplied in a W92 configuration.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BoxDownload Free CAD Model:
Technical Details:
| Packaging | Box |
| Package / Case | TO-200AB, B-PuK |
| Mounting Type | Chassis Mount |
| SCR Type | Standard Recovery |
| Operating Temperature | -60°C ~ 130°C |
| Current - Hold (Ih) (Max) | 300 mA |
| Current - Gate Trigger (Igt) (Max) | 250 mA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 19500A @ 50Hz |
| Current - On State (It (AV)) (Max) | 1315 A |
| Voltage - Gate Trigger (Vgt) (Max) | 2.5 V |
| Voltage - On State (Vtm) (Max) | 1.87 V |
| Current - Off State (Max) | 100 mA |
| Supplier Device Package | W92 |
| Current - On State (It (RMS)) (Max) | 2565 A |
| Voltage - Off State | 1.4 kV |
