IXYS N1075LN180 is a standard recovery SCR with a blocking voltage of 1.8 kV and an average on-state current rating of 1240 A (It(AV)). This chassis mount component, in a TO-200 package, offers an RMS on-state current of 2415 A (It(RMS)) and a non-repetitive surge current of 15750 A at 50 Hz. The gate trigger current (Igt) is 250 mA with a gate trigger voltage (Vgt) of 2.5 V. The on-state voltage (Vtm) is a maximum of 2.02 V, and the off-state current (Id) is 100 mA. Operating temperature range is from -60°C to 130°C. This component is suitable for high-power industrial applications, including motor control, power supplies, and welding equipment.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BoxDownload Free CAD Model:
Technical Details:
| Packaging | Box |
| Package / Case | TO-200 |
| Mounting Type | Chassis Mount |
| SCR Type | Standard Recovery |
| Operating Temperature | -60°C ~ 130°C |
| Current - Hold (Ih) (Max) | 300 mA |
| Current - Gate Trigger (Igt) (Max) | 250 mA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 15750A @ 50Hz |
| Current - On State (It (AV)) (Max) | 1240 A |
| Voltage - Gate Trigger (Vgt) (Max) | 2.5 V |
| Voltage - On State (Vtm) (Max) | 2.02 V |
| Current - Off State (Max) | 100 mA |
| Current - On State (It (RMS)) (Max) | 2415 A |
| Voltage - Off State | 1.8 kV |
