VVZB120-16IO1

RECT BRIDGE 3PH 120V 1600V V2

Manufacturer: IXYS

Categories: SCRs - Modules

Quality Control: Learn More

The IXYS VVZB120-16IO1 is a 3-phase SCR bridge module featuring a 1.6 kV blocking voltage and a 120 A average on-state current. This device integrates three SCRs and three diodes within a V2-PAK package for chassis mounting. It is designed for high-power applications requiring robust commutation and control. Key electrical specifications include a maximum gate trigger current (Igt) of 100 mA and a maximum hold current (Ih) of 200 mA. The module exhibits a non-repetitive surge current capability (Itsm) of 750 A at 50 MHz and a maximum gate trigger voltage (Vgt) of 1.5 V. Operating across a temperature range of -40°C to 150°C (TJ), this component is suitable for demanding industrial applications such as motor drives, power supplies, and welding equipment.

Additional Information

Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Box
Technical Details:
PackagingBox
Package / CaseV2-PAK
Mounting TypeChassis Mount
Operating Temperature-40°C ~ 150°C (TJ)
StructureBridge, 3-Phase - SCRs/Diodes - IGBT with Diode
Current - Hold (Ih) (Max)200 mA
Current - Gate Trigger (Igt) (Max)100 mA
Current - Non Rep. Surge 50, 60Hz (Itsm)750A @ 50MHz
Number of SCRs, Diodes3 SCRs, 3 Diodes
Current - On State (It (AV)) (Max)120 A
Voltage - Gate Trigger (Vgt) (Max)1.5 V
Voltage - Off State1.6 kV
