MMO230-14IO7
MODULE AC CONTROL 1400V ECO-PAC2Manufacturer: IXYS
Categories: SCRs - Modules
Quality Control: Learn More
IXYS MMO230-14IO7 is a 1-phase AC control SCR module featuring two SCRs with a repetitive peak off-state voltage rating of 1400V. This chassis mount module offers a maximum average on-state current of 105A and an RMS on-state current of 180A. It exhibits a surge current capability of 2250A at 50Hz and 2400A at 60Hz. The gate trigger current and voltage requirements are a maximum of 150mA and 1.5V, respectively, with a hold current maximum of 200mA. Operating within a temperature range of -40°C to 125°C, this module is suitable for applications in industrial power control, motor drives, and power supplies.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BoxDownload Free CAD Model:
Technical Details:
| Packaging | Box |
| Package / Case | Module |
| Mounting Type | Chassis Mount |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Structure | 1-Phase Controller - All SCRs |
| Current - Hold (Ih) (Max) | 200 mA |
| Current - Gate Trigger (Igt) (Max) | 150 mA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 2250A, 2400A |
| Number of SCRs, Diodes | 2 SCRs |
| Current - On State (It (AV)) (Max) | 105 A |
| Voltage - Gate Trigger (Vgt) (Max) | 1.5 V |
| Current - On State (It (RMS)) (Max) | 180 A |
| Voltage - Off State | 1.4 kV |
