CMA30P1600FC
MOD THYRISTOR DUAL 1600V I4-PACManufacturer: IXYS
Categories: SCRs - Modules
Quality Control: Learn More
SCR Module 1.6 kV 47 A Series Connection - All SCRs Through Hole i4-Pac™-5
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 15 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | i4-Pac™-5 |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Structure | Series Connection - All SCRs |
| Current - Hold (Ih) (Max) | 100 mA |
| Current - Gate Trigger (Igt) (Max) | 55 mA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 400A, 430A |
| Number of SCRs, Diodes | 2 SCRs |
| Current - On State (It (AV)) (Max) | 30 A |
| Voltage - Gate Trigger (Vgt) (Max) | 1 V |
| Current - On State (It (RMS)) (Max) | 47 A |
| Voltage - Off State | 1.6 kV |
Request a Quote
