MDI145-12A3
IGBT MODULE 1200V 160A 700W Y4M5Manufacturer: IXYS
Categories: IGBT Modules
Quality Control: Learn More
The IXYS MDI145-12A3 is a single NPT IGBT module designed for high-power applications. This component offers a collector-emitter voltage (Vce) of 1200 V and a maximum continuous collector current (Ic) of 160 A. The module features a low on-state voltage (Vce(on)) of 2.7 V at 15 V gate-emitter voltage and 100 A collector current, contributing to efficient power dissipation with a maximum power rating of 700 W. With an operating temperature range of -40°C to 150°C (TJ), it is suitable for demanding environments. The input capacitance (Cies) is specified at 6.5 nF at 25 V. Mounting is via chassis mount, and the package designation is Y4-M5. This IGBT module finds application in industrial automation, renewable energy systems, and power supply units.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BoxDownload Free CAD Model:
Technical Details:
| Packaging | Box |
| Package / Case | Y4-M5 |
| Mounting Type | Chassis Mount |
| Input | Standard |
| Configuration | Single |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Vce(on) (Max) @ Vge, Ic | 2.7V @ 15V, 100A |
| NTC Thermistor | No |
| Supplier Device Package | Y4-M5 |
| IGBT Type | NPT |
| Current - Collector (Ic) (Max) | 160 A |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Power - Max | 700 W |
| Current - Collector Cutoff (Max) | 6 mA |
| Input Capacitance (Cies) @ Vce | 6.5 nF @ 25 V |
