IXSN35N120AU1
IGBT MOD 1200V 70A 300W SOT227BManufacturer: IXYS
Categories: IGBT Modules
Quality Control: Learn More
IXYS IXSN35N120AU1 is a PT IGBT module featuring a 1200 V collector-emitter breakdown voltage and a continuous collector current rating of 70 A. This single configuration module offers a maximum power dissipation of 300 W and a low on-state voltage of 4V at 15V gate-emitter voltage and 35A collector current. The input capacitance (Cies) is 3.9 nF at 25 V. Designed for demanding applications, this component is suitable for chassis mounting utilizing the SOT-227B package. Its robust construction and operating temperature range of -55°C to 150°C make it ideal for use in industrial motor drives, renewable energy systems, and power supplies.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | SOT-227-4, miniBLOC |
| Mounting Type | Chassis Mount |
| Input | Standard |
| Configuration | Single |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Vce(on) (Max) @ Vge, Ic | 4V @ 15V, 35A |
| NTC Thermistor | No |
| Supplier Device Package | SOT-227B |
| IGBT Type | PT |
| Current - Collector (Ic) (Max) | 70 A |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Power - Max | 300 W |
| Current - Collector Cutoff (Max) | 750 µA |
| Input Capacitance (Cies) @ Vce | 3.9 nF @ 25 V |
