IXDD514D1
IC GATE DRVR LOW-SIDE 6DFNManufacturer: IXYS
Categories: Gate Drivers
Quality Control: Learn More
IXYS IXDD514D1 is a high-performance, single-channel, non-inverting low-side gate driver. This component delivers robust 14A peak source and sink current, facilitating rapid switching of power devices. With a wide supply voltage range of 4.5V to 30V and optimized rise/fall times of 25ns and 22ns respectively, it is well-suited for driving IGBTs and N-channel/P-channel MOSFETs. The device features a low logic threshold with VIL of 1V and VIH of 2.5V, ensuring compatibility with various control signals. Its 6-DFN (4x5) exposed pad package offers excellent thermal performance and is suitable for surface mounting. Applications for the IXDD514D1 include high-power motor control, power supplies, and industrial automation. The operating temperature range of -55°C to 150°C ensures reliability in demanding environments.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 6-VDFN Exposed Pad |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Voltage - Supply | 4.5V ~ 30V |
| Input Type | Non-Inverting |
| Supplier Device Package | 6-DFN (4x5) |
| Rise / Fall Time (Typ) | 25ns, 22ns |
| Channel Type | Single |
| Driven Configuration | Low-Side |
| Number of Drivers | 1 |
| Gate Type | IGBT, N-Channel, P-Channel MOSFET |
| Logic Voltage - VIL, VIH | 1V, 2.5V |
| Current - Peak Output (Source, Sink) | 14A, 14A |
| Programmable | Not Verified |
