DSEK60-12A
DIODE ARRAY GP 1200V 26A TO247ADManufacturer: IXYS
Categories: Diode Arrays
Quality Control: Learn More
The IXYS FRED series DSEK60-12A is a dual diode configuration featuring one pair of common cathode fast recovery diodes. This through-hole component, housed in a TO-247-3 package, offers a maximum DC reverse voltage of 1200V and an average rectified current of 26A per diode. Its forward voltage (Vf) is rated at a maximum of 2.55V at 30A. The device exhibits a reverse leakage current of 750 µA at 1200V and a reverse recovery time (trr) of 60 ns. Operating temperature range is from -40°C to 150°C. This component is suitable for applications in power supply, motor drive, and renewable energy systems.
Additional Information
Series: FREDRoHS Status: ROHS3 CompliantManufacturer Lead Time: 33 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-247-3 |
| Mounting Type | Through Hole |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 60 ns |
| Technology | Standard |
| Diode Configuration | 1 Pair Common Cathode |
| Current - Average Rectified (Io) (per Diode) | 26A |
| Supplier Device Package | TO-247AD |
| Operating Temperature - Junction | -40°C ~ 150°C |
| Voltage - DC Reverse (Vr) (Max) | 1200 V |
| Voltage - Forward (Vf) (Max) @ If | 2.55 V @ 30 A |
| Current - Reverse Leakage @ Vr | 750 µA @ 1200 V |
