DSEE15-12CC
DIODE ARR GP 600V 15A ISOPLUS220Manufacturer: IXYS
Categories: Diode Arrays
Quality Control: Learn More
The IXYS HiPerDynFRED™ DSEE15-12CC is a dual diode array featuring a series connection of two fast recovery diodes. This component offers a maximum DC reverse voltage of 600V and an average rectified current capability of 15A per diode. The forward voltage drop at 15A is a maximum of 2.04V. With a reverse leakage current of 100 µA at 600V, this diode array is designed for applications requiring efficient power switching. Its reverse recovery time (trr) is specified at 25 ns, classifying it as a fast recovery diode. The component is housed in an ISOPLUS220™ package, facilitating through-hole mounting. Operating junction temperatures range from -55°C to 175°C. This device is suitable for use in industrial power supplies, motor control, and uninterruptible power supplies (UPS).
Additional Information
Series: HiPerDynFRED™RoHS Status: ROHS3 CompliantManufacturer Lead Time: 48 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | ISOPLUS220™ |
| Mounting Type | Through Hole |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 25 ns |
| Technology | Standard |
| Diode Configuration | 1 Pair Series Connection |
| Current - Average Rectified (Io) (per Diode) | 15A |
| Supplier Device Package | ISOPLUS220™ |
| Operating Temperature - Junction | -55°C ~ 175°C |
| Voltage - DC Reverse (Vr) (Max) | 600 V |
| Voltage - Forward (Vf) (Max) @ If | 2.04 V @ 15 A |
| Current - Reverse Leakage @ Vr | 100 µA @ 600 V |
