VUE75-06NO7
BRIDGE RECT 3P 600V 86A ECO-PAC1Manufacturer: IXYS
Categories: Bridge Rectifiers
Quality Control: Learn More
IXYS VUE75-06NO7 is a three-phase bridge rectifier designed for robust power conversion applications. This standard technology component features a 600V peak reverse voltage rating and an average rectified current capability of 86A. The forward voltage drop at 30A is a maximum of 1.57V, with a low reverse leakage of 250µA at its maximum reverse voltage. The device is housed in the ECO-PAC1 package, facilitating efficient chassis mounting for thermal management. Operating across a wide temperature range of -40°C to 150°C (TJ), the VUE75-06NO7 is suitable for demanding industrial environments, including motor control, power supplies, and renewable energy systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 51 week(s)Product Status: ActivePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Box |
| Package / Case | ECO-PAC1 |
| Mounting Type | Chassis Mount |
| Diode Type | Three Phase |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Technology | Standard |
| Supplier Device Package | ECO-PAC1 |
| Voltage - Peak Reverse (Max) | 600 V |
| Current - Average Rectified (Io) | 86 A |
| Voltage - Forward (Vf) (Max) @ If | 1.57 V @ 30 A |
| Current - Reverse Leakage @ Vr | 250 µA @ 600 V |
