VBO160-16NO7
BRIDGE RECT 1P 1.6KV 174A PWS-EManufacturer: IXYS
Categories: Bridge Rectifiers
Quality Control: Learn More
IXYS VBO160-16NO7 is a single-phase bridge rectifier designed for robust power applications. This chassis mount component features a maximum repetitive peak reverse voltage of 1.6 kV and a substantial average rectified current handling capability of 174 A. The rectifier exhibits a typical forward voltage drop of 1.43 V at 300 A, with a low reverse leakage current of 300 µA at its maximum reverse voltage. Operating across a wide temperature range from -40°C to 150°C (TJ), the VBO160-16NO7 is housed in the PWS-E package, suitable for demanding industrial environments. Its standard technology ensures reliable performance in power conversion, motor control, and welding equipment.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 42 week(s)Product Status: ActivePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Box |
| Package / Case | PWS-E |
| Mounting Type | Chassis Mount |
| Diode Type | Single Phase |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Technology | Standard |
| Supplier Device Package | PWS-E |
| Voltage - Peak Reverse (Max) | 1.6 kV |
| Current - Average Rectified (Io) | 174 A |
| Voltage - Forward (Vf) (Max) @ If | 1.43 V @ 300 A |
| Current - Reverse Leakage @ Vr | 300 µA @ 1600 V |
