VBE60-06A
BRIDGE RECT 1P 600V 60A SOT227BManufacturer: IXYS
Categories: Bridge Rectifiers
Quality Control: Learn More
IXYS VBE60-06A is a single-phase bridge rectifier designed for robust industrial applications. This component features a 600V peak reverse voltage rating and an average rectified current capability of 60A, making it suitable for high-power rectification in applications such as industrial power supplies, motor drives, and welding equipment. The VBE60-06A utilizes standard diode technology and offers a low forward voltage drop of 1.26V at 30A, contributing to power efficiency. Its SOT-227B package facilitates efficient chassis mounting and heat dissipation, with an operating temperature range of -40°C to 150°C. The reverse leakage current is rated at 150µA at 600V.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 36 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | SOT-227-4, miniBLOC |
| Mounting Type | Chassis Mount |
| Diode Type | Single Phase |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Technology | Standard |
| Supplier Device Package | SOT-227B |
| Voltage - Peak Reverse (Max) | 600 V |
| Current - Average Rectified (Io) | 60 A |
| Voltage - Forward (Vf) (Max) @ If | 1.26 V @ 30 A |
| Current - Reverse Leakage @ Vr | 150 µA @ 600 V |
