VBE100-12NO7
BRIDGE RECT 1P 1.2KV ECO-PAC2Manufacturer: IXYS
Categories: Bridge Rectifiers
Quality Control: Learn More
IXYS FRED series single-phase bridge rectifier, part number VBE100-12NO7, offers robust performance for demanding applications. This chassis-mount component features a maximum repetitive reverse voltage of 1.2 kV and an average rectified forward current (Io) of 100 A. With a forward voltage drop (Vf) of 2.7 V at 60 A and a reverse leakage of 1 mA at 1200 V, it is engineered for efficiency. The ECO-PAC2 package ensures reliable thermal management for operation between -40°C and 150°C (TJ). This device finds application in industrial power supplies, motor drives, and renewable energy systems requiring high-voltage rectification.
Additional Information
Series: FREDRoHS Status: ROHS3 CompliantManufacturer Lead Time: 51 week(s)Product Status: ActivePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Box |
| Package / Case | ECO-PAC2 |
| Mounting Type | Chassis Mount |
| Diode Type | Single Phase |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Technology | Standard |
| Supplier Device Package | ECO-PAC2 |
| Voltage - Peak Reverse (Max) | 1.2 kV |
| Current - Average Rectified (Io) | 100 A |
| Voltage - Forward (Vf) (Max) @ If | 2.7 V @ 60 A |
| Current - Reverse Leakage @ Vr | 1 mA @ 1200 V |
