MX841BE
IC LED DRIVER RGLTR 2A 8SOICManufacturer: IXYS Integrated Circuits Division
Categories: LED Drivers
Quality Control: Learn More
The IXYS Integrated Circuits Division MX841BE is a single-output, DC-DC boost (step-up) LED driver IC. This component features an internal switch capable of handling up to 2A and supports a 20V output voltage. Operating within a supply voltage range of 1.1V to 5.5V, the MX841BE utilizes a 1MHz switching frequency for efficient power conversion. The device is housed in an 8-SOIC package suitable for surface mounting. Its design makes it well-suited for applications requiring regulated LED illumination, such as backlighting in various electronic devices. The operating temperature range for the MX841BE is -40°C to 85°C.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Voltage - Output | 20V |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Frequency | 1MHz |
| Type | DC DC Regulator |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Applications | Backlight |
| Current - Output / Channel | 2A (Switch) |
| Internal Switch(s) | Yes |
| Topology | Step-Up (Boost) |
| Supplier Device Package | 8-SOIC |
| Dimming | - |
| Voltage - Supply (Min) | 1.1V |
| Voltage - Supply (Max) | 5.5V |
