IR2235PBF
3-PHASE BRIDGE DRIVERManufacturer: International Rectifier
Categories: Gate Drivers
Quality Control: Learn More
Half-Bridge Gate Driver IC Inverting 28-DIP
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 28-DIP (0.600"", 15.24mm) |
| Mounting Type | Through Hole |
| Operating Temperature | 125°C (TJ) |
| Voltage - Supply | 10V ~ 20V |
| Input Type | Inverting |
| High Side Voltage - Max (Bootstrap) | 1200 V |
| Supplier Device Package | 28-DIP |
| Rise / Fall Time (Typ) | 90ns, 40ns |
| Channel Type | 3-Phase |
| Driven Configuration | Half-Bridge |
| Number of Drivers | 6 |
| Gate Type | IGBT, N-Channel MOSFET |
| Logic Voltage - VIL, VIH | 0.8V, 2V |
| Current - Peak Output (Source, Sink) | 250mA, 500mA |
| Programmable | Not Verified |
