AC82GS45
DRAM Controller, CMOS, PBGA1363Manufacturer: Intel
Categories: Memory Controllers
Quality Control: Learn More
The Intel AC82GS45 is a CMOS DRAM controller designed for advanced computing platforms. This component, part of the AC82GS45 series, features a PBGA1363 package with 1363 terminals, facilitating high-density interconnectivity. It supports PCI bus compatibility and incorporates low-power modes for enhanced energy efficiency. The AC82GS45 is engineered with six memory banks and utilizes a Ball Grid Array (BGA) package style for reliable surface mounting. Its operating temperature range extends up to 100°C, ensuring performance in demanding environments. This component is crucial for memory management in applications such as consumer electronics and industrial computing systems. The JEDEC code R-PBGA-B1363 specifies its advanced packaging technology. Boundary scan capabilities are integrated for streamlined testing and validation.
Additional Information
Series: AC82GS45RoHS Status: RoHS CompliantManufacturer Lead Time: Product Status: DiscontinuedPackaging: Datasheet:Download Free CAD Model:
Technical Details:
| Technology | CMOS |
| Boundary_Scan | Yes |
| Bus_Compatibility | PCI |
| JESD_30_Code | R-PBGA-B1363 |
| Low_Power_Mode | Yes |
| Number_of_Banks | 6 |
| Number_of_Terminals | 1363 |
| Operating_Temperature_Max | 100.0000 |
| Package_Body_Material | PLASTIC/EPOXY |
| Package_Code | BGA |
| Package_Shape | Rectangular |
| Package_Style | GRID ARRAY |
| Supply_Voltage_Nom | 1.0500 |
| Surface_Mount | Yes |
| Terminal_Form | Ball |
| Terminal_Position | Bottom |
| uPs_uCs_Peripheral_ICs_Type | MEMORY CONTROLLER, DRAM |
