5962-9089904MYX
Flash, 128KX8, 120ns, CQCC32Manufacturer: Intel
Categories: Flash Memories
Quality Control: Learn More
Intel 5962-9089904 series NOR Flash memory, part number 5962-9089904MYX, offers 1Mbit density with a 128K x 8 organization. This component features a maximum access time of 120ns and operates asynchronously. It is housed in a 32-terminal ceramic, metal-sealed cofired chip carrier (CQCC32) package, identified by the R-CQCC-N32 standard. Designed for harsh environments, this Intel Flash memory operates across a temperature range of -55°C to +125°C. Its CMOS technology ensures efficient performance with a typical supply voltage of 5V. This device is suitable for applications within the aerospace, defense, and industrial sectors requiring high reliability and robust memory solutions.
Additional Information
Series: 5962-9089904RoHS Status: Manufacturer Lead Time: Product Status: DiscontinuedPackaging: Datasheet:Download Free CAD Model:
Technical Details:
| Length | 13.9700 |
| Type | NOR TYPE |
| Width | 11.4300 |
| Technology | CMOS |
| Access_Time_Max | 120.0000000000000000 |
| JESD_30_Code | R-CQCC-N32 |
| Memory_Density | 1048576.0000000000000000 |
| Memory_IC_Type | FLASH |
| Memory_Organization | 128KX8 |
| Memory_Width | 8 |
| Number_of_Functions | 1 |
| Number_of_Terminals | 32 |
| Number_of_Words | 131072.0000000000000000 |
| Number_of_Words_Code | 128K |
| Operating_Mode | Asynchronous |
| Operating_Temperature_Max | 125.0 |
| Operating_Temperature_Min | -55.0 |
| Package_Body_Material | CERAMIC, METAL-SEALED COFIRED |
| Package_Code | WQCCN |
| Package_Shape | Rectangular |
| Package_Style | CHIP CARRIER, WINDOW |
| Parallel_Serial | Parallel |
| Programming_Voltage | 12 |
| Screening_Level_Reference_Standard | MIL-STD-883 |
| Seated_Height_Max | 3.1200 |
| Supply_Current_Max | 30.000000000000000 |
| Supply_Voltage_Max | 5.50000 |
| Supply_Voltage_Min | 4.50000 |
| Supply_Voltage_Nom | 5 |
| Surface_Mount | Yes |
| Terminal_Form | NO LEAD |
| Terminal_Pitch | 1.270 |
| Terminal_Position | QUAD |
