EPM7512BUC169-7N
IC CPLD 512MC 7.5NS 169UBGAManufacturer: Intel
Categories: CPLDs (Complex Programmable Logic Devices)
Quality Control: Learn More
Intel MAX® 7000B EPM7512BUC169-7N is a 512-macrocell CPLD featuring 141 I/O pins and 32 logic array blocks. This device offers a maximum propagation delay of 7.5 ns, supporting in-system programmability. The 169-UBGA package, measuring 11x11 mm, is designed for surface mounting. With an internal supply voltage range of 2.375V to 2.625V and an operating temperature range of 0°C to 70°C, the EPM7512BUC169-7N is well-suited for applications in industrial control, consumer electronics, and telecommunications. The component is supplied in trays.
Additional Information
Series: MAX® 7000BRoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 169-LFBGA |
| Mounting Type | Surface Mount |
| Programmable Type | In System Programmable |
| Number of Gates | 10000 |
| Number of Macrocells | 512 |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Delay Time tpd(1) Max | 7.5 ns |
| Supplier Device Package | 169-UBGA (11x11) |
| Number of Logic Elements/Blocks | 32 |
| Voltage Supply - Internal | 2.375V ~ 2.625V |
| Number of I/O | 141 |
| Programmable | Not Verified |
