NDT16PFJ-8KIT TR
IC DRAM 1GBIT PARALLEL 96FBGAManufacturer: Insignis Technology Corporation
Categories: Memory
Quality Control: Learn More
The Insignis Technology Corporation NDT16PFJ-8KIT-TR is a 1Gbit SDRAM DDR3 memory IC featuring a parallel interface. This component operates at an 800 MHz clock frequency with a 20 ns access time. The memory organization is 64M x 16, and it is supplied in a 96-FBGA (8x13) package, suitable for surface mounting. The device operates within a voltage range of 1.425V to 1.575V and has a write cycle time of 15 ns. The operating temperature range for this volatile memory component is -40°C to 95°C (TC). This memory solution is commonly utilized in industrial, networking, and consumer electronics applications. The NDT16PFJ-8KIT-TR is provided in tape and reel packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 96-VFBGA |
| Mounting Type | Surface Mount |
| Memory Size | 1Gbit |
| Memory Type | Volatile |
| Operating Temperature | -40°C ~ 95°C (TC) |
| Voltage - Supply | 1.425V ~ 1.575V |
| Technology | SDRAM - DDR3 |
| Clock Frequency | 800 MHz |
| Memory Format | DRAM |
| Supplier Device Package | 96-FBGA (8x13) |
| Write Cycle Time - Word, Page | 15ns |
| Memory Interface | Parallel |
| Access Time | 20 ns |
| Memory Organization | 64M x 16 |
| Programmable | Not Verified |
