BBY5603WE6327HTSA1
DIODE TUNING 10V 20MA SOD-323Manufacturer: Infineon Technologies
Categories: Variable Capacitance (Varicaps, Varactors)
Quality Control: Learn More
Infineon Technologies BBY5603WE6327HTSA1 is a single varactor diode designed for surface mount applications. This component features a reverse breakdown voltage of 10V and a maximum forward current of 20mA. With a typical capacitance of 12.1pF at 4V and 1MHz, it offers a capacitance ratio of 3.3 (C1/C3). The device is housed in a PG-SOD323-3D package, also known as SC-76, and is supplied on tape and reel. Operating across a temperature range of -55°C to 150°C, this varactor is suitable for use in tuning circuits, voltage-controlled oscillators (VCOs), and frequency modulation applications within the telecommunications and consumer electronics industries.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SC-76, SOD-323 |
| Mounting Type | Surface Mount |
| Diode Type | Single |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Capacitance @ Vr, F | 12.1pF @ 4V, 1MHz |
| Q @ Vr, F | - |
| Capacitance Ratio Condition | C1/C3 |
| Supplier Device Package | PG-SOD323-3D |
| Voltage - Peak Reverse (Max) | 10 V |
| Capacitance Ratio | 3.3 |
