ESD8V0L2B03LE6327XTMA1
TVS DIODE 22VWM 26VC TSLP-3-1Manufacturer: Infineon Technologies
Categories: TVS Diodes
Quality Control: Learn More
Infineon Technologies ESD8V0L2B03LE6327XTMA1 is a bidirectional transient voltage suppressor (TVS) diode designed for robust circuit protection. This component features a 22V reverse standoff voltage and a low 26V clamping voltage at a peak pulse current of 2.5A (8/20µs). With a low capacitance of 4pF at 1MHz, it minimizes signal integrity impact. The device is housed in a compact PG-TSLP-3-1 package, suitable for surface mounting. Operating across a wide temperature range of -55°C to 125°C, this TVS diode is ideal for general-purpose applications in automotive, industrial, and consumer electronics where protection against voltage transients is critical.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SC-101, SOT-883 |
| Mounting Type | Surface Mount |
| Type | Zener |
| Operating Temperature | -55°C ~ 125°C (TJ) |
| Applications | General Purpose |
| Capacitance @ Frequency | 4pF @ 1MHz |
| Current - Peak Pulse (10/1000µs) | 2.5A (8/20µs) |
| Voltage - Reverse Standoff (Typ) | 22V (Max) |
| Supplier Device Package | PG-TSLP-3-1 |
| Bidirectional Channels | 2 |
| Voltage - Breakdown (Min) | 23V (Typ) |
| Voltage - Clamping (Max) @ Ipp | 26V (Typ) |
| Power - Peak Pulse | - |
| Power Line Protection | No |
