TLE4955CE2AAMA1
MAG SWITCH SPEC PURP SSO-2-53Manufacturer: Infineon Technologies
Categories: Switches (Solid State)
Quality Control: Learn More
Infineon Technologies TLE4955CE2AAMA1 is a digital Hall effect switch designed for specialized applications. This component features a PG-SSO-2-53 package suitable for through-hole mounting. Operating from a 4V to 20V supply, it offers a maximum output current of 16mA and a supply current of 8mA. The device supports both North and South pole detection and provides a PWM output signal. Qualified to AEC-Q100 standards, the TLE4955CE2AAMA1 is rated for automotive applications, functioning within an operating temperature range of -40°C to 110°C. Its sensing capabilities include trip and release points of 30mT. This component is commonly utilized in automotive systems, including those requiring precise magnetic field sensing for position detection or speed measurement.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: Last Time BuyPackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | 2-SIP, SSO-2-53 |
| Output Type | PWM |
| Polarization | North Pole, South Pole |
| Mounting Type | Through Hole |
| Function | Special Purpose |
| Operating Temperature | -40°C ~ 110°C |
| Voltage - Supply | 4V ~ 20V |
| Technology | Hall Effect |
| Sensing Range | -30mT Trip, 30mT Release |
| Current - Output (Max) | 16mA |
| Current - Supply (Max) | 8mA |
| Supplier Device Package | PG-SSO-2-53 |
| Test Condition | 25°C |
| Grade | Automotive |
| Qualification | AEC-Q100 |
