PVN012S-T
SSR RELAY SPST-NO 2.5A 0-20VManufacturer: Infineon Technologies
Categories: Solid State Relays (SSR)
Quality Control: Learn More
Infineon Technologies PVN012S-T HEXFET® Solid State Relay offers a single-pole, single-throw normally open (SPST-NO) configuration. This surface-mount device, packaged in a 6-SMD (0.300", 7.62mm) with gull-wing termination, is designed for applications requiring reliable switching of loads up to 2.5A. The PVN012S-T features a low on-state resistance of 100 MOhms (max) and operates across a load voltage range of 0V to 20V. Its input voltage is rated at 1.2VDC. This component is suitable for various industrial automation, power control, and telecommunications systems. The device operates within an ambient temperature range of -40°C to 85°C and is UL approved. It is supplied in Tape & Reel packaging.
Additional Information
Series: PVN, HEXFET®RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 6-SMD (0.300"", 7.62mm) |
| Output Type | AC, DC |
| Mounting Type | Surface Mount |
| Voltage - Input | 1.2VDC |
| Circuit | SPST-NO (1 Form A) |
| Operating Temperature | -40°C ~ 85°C |
| Termination Style | Gull Wing |
| Load Current | 2.5 A |
| Approval Agency | UL |
| Supplier Device Package | 6-SMT |
| Grade | - |
| Voltage - Load | 0 V ~ 20 V |
| On-State Resistance (Max) | 100 MOhms |
| Qualification | - |
