IKZA100N65EH7XKSA1
IGBT TRENCH FS 650V 140A TO247-4Manufacturer: Infineon Technologies
Categories: Single IGBTs
Quality Control: Learn More
IGBT Trench Field Stop 650 V 140 A 429 W Through Hole PG-TO247-4-3
Additional Information
Series: TrenchStop™RoHS Status: ROHS3 CompliantManufacturer Lead Time: 19 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-247-4 |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Input Type | Standard |
| Reverse Recovery Time (trr) | 62 ns |
| Vce(on) (Max) @ Vge, Ic | 1.65V @ 15V, 100A |
| Supplier Device Package | PG-TO247-4-3 |
| IGBT Type | Trench Field Stop |
| Td (on/off) @ 25°C | 32ns/240ns |
| Switching Energy | 1.24mJ (on), 1.22mJ (off) |
| Test Condition | 400V, 100A, 10Ohm, 15V |
| Gate Charge | 207 nC |
| Grade | - |
| Current - Collector (Ic) (Max) | 140 A |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
| Current - Collector Pulsed (Icm) | 400 A |
| Power - Max | 429 W |
| Qualification | - |
