IKW25N120T2FKSA1

IGBT TRENCH 1200V 50A TO247-3

Manufacturer: Infineon Technologies

Categories: Single IGBTs

Quality Control: Learn More

Infineon Technologies TrenchStop® IKW25N120T2FKSA1 is a high-performance IGBT with a collector-emitter breakdown voltage of 1200 V. This device features a continuous collector current capability of 50 A, with a pulsed current rating (Icm) of 100 A. The Trench IGBT technology ensures efficient switching characteristics, as evidenced by a typical turn-on delay (Td(on)) of 27 ns and turn-off delay (Td(off)) of 265 ns at 25°C (tested at 600V, 25A, 16.4 Ohm, 15V). The on-state voltage (Vce(on)) is a maximum of 2.2V at 15V gate-emitter voltage and 25A collector current. With a maximum power dissipation of 349 W and an operating temperature range of -40°C to 175°C, this component is suitable for demanding applications in power factor correction, motor drives, and uninterruptible power supplies. It is supplied in a PG-TO247-3-1 package, designed for through-hole mounting. The gate charge is 120 nC, and the reverse recovery time (trr) is 195 ns.

Additional Information

Series: TrenchStop®RoHS Status: ROHS3 CompliantManufacturer Lead Time: 19 week(s)Product Status: Not For New DesignsPackaging: TubeDatasheet:
Technical Details:
PackagingTube
Package / CaseTO-247-3
Mounting TypeThrough Hole
Operating Temperature-40°C ~ 175°C (TJ)
Input TypeStandard
Reverse Recovery Time (trr)195 ns
Vce(on) (Max) @ Vge, Ic2.2V @ 15V, 25A
Supplier Device PackagePG-TO247-3-1
IGBT TypeTrench
Td (on/off) @ 25°C27ns/265ns
Switching Energy2.9mJ
Test Condition600V, 25A, 16.4Ohm, 15V
Gate Charge120 nC
Current - Collector (Ic) (Max)50 A
Voltage - Collector Emitter Breakdown (Max)1200 V
Current - Collector Pulsed (Icm)100 A
Power - Max349 W
