MMBD914LT1HTSA1
DIODE GEN PURP 100V 250MA SOT23Manufacturer: Infineon Technologies
Categories: Single Diodes
Quality Control: Learn More
Infineon Technologies MMBD914LT1HTSA1 is a general-purpose diode designed for high-speed switching applications. This SOT-23 package device offers a reverse voltage rating of 100V and a forward current handling capability of 250mA. Featuring a low forward voltage drop of 1.25V at 150mA and a fast reverse recovery time of 4ns, it is suitable for applications requiring efficient rectification and fast switching. The capacitance at 0V and 1MHz is 2pF, and the reverse leakage current is minimal at 100 nA @ 75 V. Operating reliably up to a junction temperature of 150°C, this diode finds utility in consumer electronics, industrial control systems, and telecommunications equipment.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Mounting Type | Surface Mount |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 4 ns |
| Technology | Standard |
| Capacitance @ Vr, F | 2pF @ 0V, 1MHz |
| Current - Average Rectified (Io) | 250mA |
| Supplier Device Package | PG-SOT23 |
| Operating Temperature - Junction | 150°C (Max) |
| Voltage - DC Reverse (Vr) (Max) | 100 V |
| Voltage - Forward (Vf) (Max) @ If | 1.25 V @ 150 mA |
| Current - Reverse Leakage @ Vr | 100 nA @ 75 V |
