BGS14MPA9E6327XTSA1
IC RF SWITCH SP4T 6GHZ ATSLP9-3Manufacturer: Infineon Technologies
Categories: RF Switches
Quality Control: Learn More
Infineon Technologies BGS14MPA9E6327XTSA1 is a high-performance Single Pole Four Throw (SP4T) RF switch IC designed for demanding wireless applications. This device offers excellent performance across a broad frequency range from 50MHz to 6GHz, making it suitable for 2G, 3G, 4G, and 5G cellular infrastructure, including LTE and W-CDMA systems. Key specifications include an insertion loss of 1dB and an isolation of 23dB at the test frequency of 5.925GHz. The switch exhibits a high IIP3 of 77dBm, ensuring linearity in complex signal environments. It operates with a supply voltage between 1.65V and 1.95V and features DC blocking. The BGS14MPA9E6327XTSA1 is housed in a compact PG-ATSLP-9-3 package, a 9-UFQFN, for surface mounting, and is supplied on a tape and reel. Its robust operating temperature range extends to 125°C (TJ).
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | DC Blocked |
| Packaging | Tape & Reel (TR) |
| Package / Case | 9-UFQFN |
| Impedance | 50Ohm |
| Mounting Type | Surface Mount |
| Circuit | SP4T |
| RF Type | 2G/3G/4G/5G, Cellular, LTE, W-CDMA |
| Operating Temperature | 125°C (TJ) |
| Voltage - Supply | 1.65V ~ 1.95V |
| Insertion Loss | 1dB |
| Frequency Range | 50MHz ~ 6GHz |
| Topology | - |
| P1dB | - |
| Test Frequency | 5.925GHz |
| Isolation | 23dB |
| Supplier Device Package | PG-ATSLP-9-3 |
| IIP3 | 77dBm |
