TDA7210V
RF RX ASK/FSK 810-870MHZ 32VQFNManufacturer: Infineon Technologies
Categories: RF Receivers
Quality Control: Learn More
Infineon Technologies TDA7210V is an RF receiver supporting ASK and FSK modulation across the 810MHz to 870MHz and 400MHz to 440MHz bands. This component offers a sensitivity of -107dBm at a maximum data rate of 100Kbps. Designed for surface mounting with a PCB antenna connector, it is housed in a 32-VQFN (5.5x4.5) package. The receiver operates with a supply voltage range of 4.5V to 5.5V and draws 5.9mA during reception. Key features include RSSI, making it suitable for applications in Remote Keyless Entry (RKE), telemetering, and security technology. The operating temperature range is -40°C to 85°C.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | RSSI Equipped |
| Packaging | Tape & Reel (TR) |
| Package / Case | 32-VFQFN Exposed Pad |
| Sensitivity | -107dBm |
| Mounting Type | Surface Mount |
| Frequency | 810MHz ~ 870MHz, 400MHz ~ 440MHz |
| Memory Size | - |
| Modulation or Protocol | ASK, FSK |
| Data Interface | PCB, Surface Mount |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 4.5V ~ 5.5V |
| Applications | RKE, Telemetering, Security Technology |
| Current - Receiving | 5.9mA |
| Data Rate (Max) | 100Kbps |
| Antenna Connector | PCB, Surface Mount |
| Supplier Device Package | 32-VQFN (5.5x4.5) |
