BGA461E6327XTSA1
IC RF AMP GPS 1575.42MHZ TSLP7-4Manufacturer: Infineon Technologies
Categories: RF Amplifiers
Quality Control: Learn More
Infineon Technologies BGA461E6327XTSA1 is a high-performance RF amplifier designed for Global Positioning System (GPS) applications. This device operates at a frequency of 1575.42MHz, a critical band for GPS signals. It features a nominal gain of 19.5dB, ensuring robust signal reception. The amplifier exhibits an excellent noise figure of 1.1dB, crucial for detecting weak satellite signals. With a P1dB compression point of -14dBm, it maintains linearity under moderate signal conditions. The BGA461E6327XTSA1 is supplied in a compact PG-TSLP-7-4 package, a 6-XDFN with an exposed pad, suitable for surface mounting. It operates from a low supply voltage of 2.4V to 3.2V and draws a minimal current of 4mA, making it ideal for power-sensitive systems found in automotive, telecommunications, and portable navigation devices. The component is provided on a Tape & Reel (TR) for automated assembly processes.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 6-XDFN Exposed Pad |
| Mounting Type | Surface Mount |
| Frequency | 1575.42MHz |
| RF Type | GPS |
| Voltage - Supply | 2.4V ~ 3.2V |
| Gain | 19.5dB |
| Current - Supply | 4mA |
| Noise Figure | 1.1dB |
| P1dB | -14dBm |
| Test Frequency | 1575.42MHz |
| Supplier Device Package | PG-TSLP-7-4 |
