BSP78 E6327
IC PWR SWTCH N-CHAN 1:1 SOT223-4Manufacturer: Infineon Technologies
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
Infineon Technologies presents the HITFET® BSP78-E6327, an N-channel power switch designed for high-side switching applications. This device features a low Rds(on) of typically 35mOhm and supports a maximum load voltage of 42V with a continuous output current of up to 3A. Integrated fault protection includes fixed current limiting, over-temperature, and over-voltage protection, complemented by an auto-restart feature. The BSP78-E6327 is supplied in a PG-SOT223-4 package for surface mounting and operates within an ambient temperature range of -40°C to 150°C. This robust power switch is suitable for demanding applications in the automotive and industrial sectors, facilitating efficient power distribution and load management.
Additional Information
Series: HITFET®RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Auto Restart |
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-261-4, TO-261AA |
| Output Type | N-Channel |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Interface | ON/OFF |
| Switch Type | General Purpose |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | Low Side |
| Rds On (Typ) | 35mOhm |
| Input Type | Non-Inverting |
| Voltage - Load | 42V (Max) |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 3A |
| Ratio - Input:Output | 1:1 |
| Supplier Device Package | PG-SOT223-4 |
| Fault Protection | Current Limiting (Fixed), Over Temperature, Over Voltage |
