BTN7970S
HALF-BRIDGE PERIPHERAL DRIVERManufacturer: Infineon Technologies
Categories: Motor Drivers, Controllers
Quality Control: Learn More
Infineon Technologies NovalithIC™ series BTN7970S is a highly integrated half-bridge power stage driver. This DMOS technology device is designed for unipolar stepper motor control, offering a robust solution for demanding applications. The BTN7970S features an output current capability of 90A and operates with a supply voltage range of 8V to 18V. Its P-TO220-7-11 package with formed leads ensures efficient thermal management and ease of through-hole mounting. This component is suitable for automotive applications requiring precise motor control and high current handling. The encapsulated design integrates control and power stages for simplified system design.
Additional Information
Series: NovalithIC™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | TO-220-7 Formed Leads |
| Mounting Type | Through Hole |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Current - Output | 90A |
| Interface | - |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | Half Bridge |
| Voltage - Supply | 8V ~ 18V |
| Applications | - |
| Technology | DMOS |
| Voltage - Load | - |
| Supplier Device Package | P-TO220-7-11 |
| Motor Type - Stepper | Unipolar |
| Motor Type - AC, DC | - |
| Step Resolution | - |
| Grade | Automotive |
